PRODUCTS

Dry-wet hybrid cooler

Home page

FBF Series Combined-Flow Single-Air Inlet Closed Cooling Tower

The combined-flow closed cooling tower is the most efficient closed cooling tower on the market. The combined-flow cooling tower positions the process refrigerant in a clean, fully enclosed circuit, free from contamination, decreasing maintenance workload and merging the functions of the cooling tower and heat exchanger for good operating and maintenance performance.

FBF Series Combined-Flow Double-Air Inlet Closed Cooling Tower

① The double-air inlet closed cooling tower is based on a single-air inlet design, with two coolers and PVC heat exchange layers, sharing a fan system, achieving higher performance and lowering energy consumption in a limited flat area ② The double-air inlet evaporative condenser with only one module can realize a higher industrial capacity. So, the double-air inlet combined-flow closed cooling tower is the ideal selection for large projects ③ Two ways of coils can cool different media in the same tower ④ Two coolers can complete cooling cycles and appropriate for medium and high-temperature conditions

FNB series countercurrent closed cooling tower

Compact structure, small footprint, can be combined with multiple units, to meet the requirements of various water volumes, size and temperature difference, suitable for conventional cooling projects. The inlet air form of the counter-flow cooling tower is the bottom counter-current inlet air, which alternates with the falling spray water in reverse to form saturated humid hot air, the heat is discharged by the top fan, and the water is blocked back to the collection tank by the special structure dehydrator for recycling, which has a compact structure and occupies a small area.

FKH series square cross flow open cooling tower

International design conditions of cooling tower: inlet water temperature t1=37°C; Outlet temperature t2=32°C; Wet bulb temperature t=28°C; Dry bulb temperature θ=31.5°C; Atmospheric pressure = 9.94X104pa. The company's standard cooling tower is designed according to the national design conditions. It can also provide customers with special, special designs under non-standard working conditions. Due to site restrictions or styling needs, the company can carry out special design and customization according to the size required by the customer, and contact us for details. Each supporting surface of the foundation is on the same horizontal plane, and its elevation and size error should be less than 5mm.

FKN series square counter flow open cooling tower

New technology: the whole heat sink developed by new technology is used to optimize the design structure and make the volume more reasonable. New material: the improved flame-retardant PVC raw material is used as the heat sink material, and the FRP is made of the improved material of the United States. New process: the use of blister mold one-time molding, the structure adopts weldless assembly, fast and strong.

FKY series circular countercurrent open cooling tower

The overall structure is solid and lightweight, and the body and water basin are made of reinforced glass fiber (FRP fiberglass), which is not easy to corrode. The surface coat is supplemented with UV inhibitors to resist sunlight damage. All steel materials are hot-dip galvanized for corrosion resistance and durability.

< 1 >
